19. MAINTENANCE FUNCTION

933

Cause and ResponseMessage

S SRAM DATA BACKUP

ERROR.

HIT SELECT KEY.

An attempt to write a backup file to a memory

card failed.

Check that the memory card is normal.

Check that the memory card’s battery is not

exhausted, that its circuitry has not been

damaged, and that it is securely inserted into

its slot.

SRAM PARITY

OCCURRED.

PLEASE POWER OFF.

A parity error was detected during backup

operation of SRAM (Note).

NOTE Action to be taken when an SRAM parity error is detected during

backup of SRAM in the boot system

The SRAM area of each CNC shipped from the factory is cleared

and is free of parity errors. However, shock applied to the CNC dur-

ing transportation may cause a parity error in the SRAM area. If the

backup battery of the CNC is dead, a parity error can occur in the

SRAM area. If a parity error occurs in the SRAM area, the data held

in the SRAM area is not guaranteed. However, the CNC does not

always use the entire SRAM area. A parity error is not detected by

hardware unless the part containing the error is read. Therefore,

if a parity error occurs in an area not accessed by the CNC, the

CNC may operate normally. The SRAM backup function of the boot

system reads the entire SRAM area. So, a parity error may occur

in the middle of backup operation even when the CNC has oper-

ated normally. In this case, the SRAM data of the CNC is not guar-

anteed, and the data cannot be backed up using the SRAM backup

function of the boot system. Nevertheless, the CNC may operate

normally. So, it is recommended that necessary data be backed

up using the Floppy Cassette or Handy File, data all clear operation

be performed, then the backed up data be restored in the CNC.

Once all clear operation is performed, the parity error can be re-

moved. Then, the SRAM backup function of the boot system can

be used.

D If an error occurs, the corresponding error message appears on the

screen, together with the message “HIT SELECT KEY.” Note that the

[SELECT] soft key is disabled for errors whose clearing requires that

the power be turned off.
