7. PARAMETERS

389

06204 Multi-step skip signal selection

#0 3S1 : For G31 P3/G04 Q3, the SKIP signal is not

used (0)/used (1).

#1 3S2 : For G31 P3/G04 Q3, the SKIP2 signal is not

used (0)/used (1).

#2 3S3 : For G31 P3/G04 Q3, the SKIP3 signal is not

used (0)/used (1).

#3 3S4 : For G31 P3/G04 Q3, the SKIP4 signal is not

used (0)/used (1).

#4 3S5 : For G31 P3/G04 Q3, the SKIP5 signal is not

used (0)/used (1).

#5 3S6 : For G31 P3/G04 Q3, the SKIP6 signal is not

used (0)/used (1).

#6 3S7 : For G31 P3/G04 Q3, the SKIP7 signal is not

used (0)/used (1).

#7 3S8 : For G31 P3/G04 Q3, the SKIP8 signal is not

used (0)/used (1).

06205 Multi-step skip signal selection

#0 4S1 : For G31 P4/G04 Q4, the SKIP signal is not

used (0)/used (1).

#1 4S2 : For G31 P4/G04 Q4, the SKIP2 signal is not

used (0)/used (1).

#2 4S3 : For G31 P4/G04 Q4, the SKIP3 signal is not

used (0)/used (1).

#3 4S4 : For G31 P4/G04 Q4, the SKIP4 signal is not

used (0)/used (1).

#4 4S5 : For G31 P4/G04 Q4, the SKIP5 signal is not

used (0)/used (1).

#5 4S6 : For G31 P4/G04 Q4, the SKIP6 signal is not

used (0)/used (1).

#6 4S7 : For G31 P4/G04 Q4, the SKIP7 signal is not

used (0)/used (1).

#7 4S8 : For G31 P4/G04 Q4, the SKIP8 signal is not

used (0)/used (1).

06206 Multi-step skip signal selection

#0 DS1 : For G04, the SKIP signal is not used (0)/used

(1).

#1 DS2 : For G04, the SKIP2 signal is not used (0)/used

(1).

#2 DS3 : For G04, the SKIP3 signal is not used (0)/used

(1).

#3 DS4 : For G04, the SKIP4 signal is not used (0)/used

(1).

#4 DS5 : For G04, the SKIP5 signal is not used (0)/used

(1).

#5 DS6 : For G04, the SKIP6 signal is not used (0)/used

(1).

#6 DS7 : For G04, the SKIP7 signal is not used (0)/used

(1).

#7 DS8 : For G04, the SKIP8 signal is not used (0)/used

(1).
