7.2 Parameter List

280

01603 Acceleration/deceleration control

#3 SBL : In high–precision contour control, the

bell–shaped acceleration/deceleration before

interpolation is performed, with a constant

acceleration change(0)/with a constant

acceleration time(1) (Set the time constant in

PRM8416.)

#4 RPT : The acceleration/deceleration of

interpolation–type rapid traverse is performed,

with a constant inclination(0)/with a constant

time(1)

#6 RBL : In the AI contour control mode,

acceleration/deceleration of rapid traverse is,

linear acceleration/deceleration(0)/bell–shaped

acceleration/deceleration(1)

#7 BEL : In AI contour control mode is linear

acceleration/deceleration before look–ahead

interpolation (0)/bell–shaped

acceleration/deceleration before look–ahead

interpolation (1)

M series

01610 Acceleration/deceleration control <Axis>

CTBx

CTBx Acceleration/deceleration

0 Exponential acceleration/

deceleration

0 1 Linear acceleration/decel-

eration after interpolation

1 0 Bell–shaped acceleration/

deceleration after interpola-

tion

#0 CTL :

#1 CTB :

#4 JGL : Acceleration/deceleration for manual feed is

exponential (0)/linear or bell-shaped (1).

PRM1622

PRM

1610#0,#1,

1624

01620 Time constant of linear acceleration/

deceleration in rapid traverse for each axis or

time constant T1 of bell–shaped

acceleration/deceleration in rapid traverse for

each axis [msec]

<Axis>

01621 Time constant T2 used in bell-shaped

acceleration/deceleration in rapid traverse for

each axis [msec]

<Axis>

01622 Time constant of exponential function

acceleration/deceleration in cutting feed for

each axis [msec]

<Axis>

01623 FL rate of exponential function acceleration/

deceleration in cutting feed for each axis

[mm/min]

<Axis>

01624 Time constant of exponential function

acceleration/deceleration in jog feed for each

axis [msec]

<Axis>
