8. ALARM LIST

563

SPM

indica-

tion(*1)

Description

Faulty location and

remedy

10 During execution of the Cs

contour axis control com-

mand, do not specify another

operation mode. Before en-

tering another mode, cancel

the Cs contour control com-

mand.

Although Cs contour control mode is set,

another operation mode (servo mode,

spindle synchronization, or orientation)

is specified.

11 During execution of the servo

mode command, do not spec-

ify another operation mode.

Before entering another

mode, cancel the servo

mode.

Although servo mode (rigid tapping, or

spindle positioning) is set, another op-

eration mode (Cs contour control,

spindle synchronization, or orientation)

is specified.

12 During execution of the

spindle synchronization com-

mand, do not specify another

operation mode. Before en-

tering another mode, cancel

the spindle synchronization

command.

Although spindle synchronization is be-

ing performed, another operation mode

(Cs contour control, servo mode, or

orientation) is specified.

13 During execution of the

orientation command, do not

specify another operation

mode. Before entering anoth-

er mode, cancel the orienta-

tion command.

Although the orientation command is be-

ing executed, another operation mode

(Cs contour control, servo mode, or syn-

chronization) is specified.

14 Input the SFT or SRV signal. The SFT and SRV signals are both input

at the same time.

15 Check PRM4000#5 and PMC

signal (CON).

When PRM4000#5 is set to 1 to indicate

the presence of the differential speed

mode function, Cs contour control is spe-

cified.

16 Check PRM4000#5 and PMC

signal (DEFMD).

When PRM4000#5 is set to 0 to indicate

the absence of the differential speed

mode function, the differential speed

mode command (DEFMD) is input.

17 Check PRM4011#2, #1, #0. Setting of the speed detector parameter

(PRM4011#2, #1, #0) is invalid. (The

corresponding speed detector is not

present.)

18 Check PRM4001#2 and PMC

signal (ORCM).

Although PRM4001#2 is set to 0 not to

use the position coder signal, a com-

mand for orientation by a position coder

(ORCMA) is input.

19 During execution of the

orientation command, do not

specify another operation

mode. Before entering anoth-

er mode, cancel the orienta-

tion command.

Although orientation by a magnetic sen-

sor is being performed, another opera-

tion mode is specified.

20 Check PRM4001#5, 4014#5,

and 4018#4.

When the use of the slave operation

mode function is set (PRM4014#5=1),

the use of a high–resolution magnetic

pulse coder (PRM4001#5=1) or the use

of the Cs contour control function by the

sensor (PRM4018#4=1) is specified.

These items cannot be set at the same

time.
