8.1 Alarms Displayed on NC Screen

494

No. ContentsMessage

5448 CRC:INTERFERENCE TO

AVD.

(M series)

In the interference check evade function of

cutter compensation, a further interference

occurs for an already created interference

evade vector.

5452 IMPROPER G–CODE

(5AXIS MODE)

(M series)

A G code that cannot be specified is found.

(5–axis mode)

This alarm is issued when:

1) Three–dimensional cutter compensa-

tion (side–face offset and leading–

edge offset) is applied during cutter

compensation, or cutter compensation

is applied during three–dimensional

cutter compensation (side–face offset

and leading–edge offset).

2) A leading–edge offset of three–dimen-

sional cutter compensation is applied

during side–face offsetting of three–di-

mensional cutter compensation, or a

side–face offset of three–dimensional

cutter compensation is applied during

leading–edge offsetting of three–di-

mensional cutter compensation.

3) Tool axis direction tool length com-

pensation is applied during tool length

compensation, or tool length com-

pensation is applied during tool axis

direction tool length compensation.

4) Tool center point control is provided

during tool length compensation, or

tool length compensation is applied

during tool center point control.

5) Tool center point control is provided

during tool axis direction tool length

compensation, or tool axis direction

tool length compensation is applied

during tool center point control.

If this alarm is issued, cancel the rele-

vant mode, then specify a different

mode.

5453 NOTE: G68 IS CANCELED

(HPCC)

(M series)

When PRM5400#2 is set to 1, and a reset

does not cancel G68, this alarm is issued

at the time of program restart. To release

this alarm, press <RESET> and <CAN>.

Once this operation is performed, the alarm

will not be issued at the next restart.

5455 ILLEGAL ACC.

PARAMETER

(M series)

A permissible acceleration parameter for

optimum torque acceleration/deceleration

is incorrect. The cause is one of the follow-

ing:

1) The ratio of the deceleration rate to the

acceleration rate is below the limit.

2) The time required for deceleration to a

speed of 0 exceeds the maximum val-

ue.

NOTE HPCC designates High–Precision Contour Control. AICC desig-

nates AI Contour Control.
