6.3 Matters Common to Both LCD–Mounted Type and

Stand–Alone Type i Series

250

5 Press the nine compensation points (marked with +) with touch panel

pen. You may press the nine points in any order. When you press a +

mark correctly, the + mark blinks. When you press a + point incorrectly,

the message “CALIBRATED POINT DOES NOT MATCH, PLEASE

PUSH AGAIN.” appears.

6 After pressing all of the nine compensation points, press the <INPUT>

key to terminate compensation. To cancel compensation or start all

over again, press the <CAN> key.

7 Upon normal termination, the message “CALIBRATION WAS ENDED.”

appears.

8 Pressing the function key exits from the touch panel compensation

screen, and terminates or stops compensation operation.

9 Upon termination of compensation operation, set PRM3113#5 (DTPCL)

to 0.

NOTE Touch panel of the CNC display unit with PC functions is compen-

sated by the exclusive program.

When compensating the touch panel for the is series, select [Start]

→ [Settings] → [Control Panel] → [Adjusting Stylus], instead of us-

ing the above method.
