19. MAINTENANCE FUNCTION

899

READ

O0001 N00010

PROGRAM (NUM.) MEMORY (CHAR.)

USED : 60 3321

FREE : 2 429

O0010 O0001 O0003 O0002 O0555 O0999

O0062 O0004 O0005 O1111 O0969 O6666

O0021 O1234 O0588 O0020 O0040

EDIT * * * * * * * * * * * * * 14:46:09

F SRH

[][][][][]

PUNCH DELETE (OPRT)

4 Enter address N.

5 Enter the number of the file to be found.

⋅ N0

The first floppy file is found.

⋅ One of N1 to N9999

Among the files numbered from 1 to 9999, a specified file is found.

⋅ N–9999

The file immediately after that used most recently is found.

⋅ N–9998

When –9998 is specified, the next file is found. Then, each time a

file input/output operation is performed, N–9999 is automatically

inserted. This means that subsequent files can be sequentially

found automatically.

This state is canceled by specifying N0, N1 to N9999, or N–9999,

or upon a reset.

6 Press soft keys [F SRH] and [EXEC].

The specified file is found.

EXECCAN

(2) Inputting a program

1 Press soft key [PRGRM] on the ALL IO screen.

2 Select EDIT mode. A program directory is displayed.

3 Press soft key [(OPRT)]. The screen and soft keys change as shown

below.

⋅ A program directory is displayed only in EDIT mode. In all other

modes, the ALL IO screen is displayed.
