Series 16i/18i/21i/160i/180i/210i/160is/180is/210is - Model B Operation and maintenance handbook Page 618

Operation and maintenance handbook

Page of 992

/ 992

9. SIGNAL LIST (X/Y, G/F)

585

Symbol

series

AddressSignal name

SORENA F047#3 f f

SORENB

Synchronization orientation

F051#3 f f

SORENC

permission signal

(serial spindle)

F170#3 f f

SOREND

(serial spindle)

F268#3 f f

SOV0 to SOV7 Spindle speed override

signal

G030 f f

SPAL Spindle fluctuation

detection alarm signal

F035#0 f f

SPL Feed hold lamp signal F000#4 f f

SPO Software operator’s panel

signal (*SP)

F075#7 f f

SPPHS Spindle phase synchronous

control signal

G038#3 f f

SPSLA G071#2 f f

SPSLB

Spindle select signal

G075#2 f f

SPSLC

Spindle select signal

(serial spindle)

G205#2 f f

SPSLD G267#2 f f

SPSTP Spindle stop complete

signal

G028#6 f –

SPSYC Spindle synchronous

control signal

G038#2 f f

SPWRN1 to 9 Spindle warning detail

signal

F264#0 to

#7, F265#1

f f

SRLNI0 to

SRLNI3

Group number specification

signals

G091#0 to

f f

SRLNO0 to

SRLNO3

Group number output

signals

F178#0 to

f f

SRN Program restart signal G006#0 f f

SRNMV Program restart under way

signal

F002#4 f f

SRVA G070#4 f f

SRVB

CCW command signal

G074#4 f f

SRVC

CCW command signal

(serial spindle)

G204#4 f f

SRVD G266#4 f f

SSIN G033#6 f f

SSIN2

Spindle motor command

G035#6 f f

SSIN3

Spindle motor command

polarity select signal

G037#6 f f

SSIN4 G273#6 f f

SSTA F045#1 f f

SSTB

Speed zero signal

F049#1 f f

SSTC

Speed zero signal

(serial spindle)

F168#1 f f

SSTD F266#1 f f

ST Cycle start lamp signal G007#2 f f

STL Cycle start signal F000#5 f f

STLK Start lock signal G007#1 f –
