7. PARAMETERS

311

03126 Modal G code display

#0 D17 : On program check screen display, the 17

group G code is display (0)/not displayed (1)

#1 D18 : On program check screen display, the 18

group G code is display (0)/not displayed (1)

#2 D19 : On program check screen display, the 19

group G code is display (0)/not displayed (1)

#3 D20 : On program check screen display, the 20

group G code is display (0)/not displayed (1)

#4 D21 : On program check screen display, the 21

group G code is display (0)/not displayed (1)

#5 D22 : On program check screen display, the 22

group G code is display (0)/not displayed (1)

#6 D23 : On program check screen display, the 23

group G code is display (0)/not displayed (1)

#7 D24 : On program check screen display, the 24

group G code is display (0)/not displayed (1)

03127 Modal G code display

#0 D25 : On program check screen display, the 25

group G code is display (0)/not displayed (1)

03130 Axis display order for current position display

screens

T series

2-path

control

03131 Subscript for the name of each axis 2-path

control

03132 Axis name (absolute coordinate) for current

position display

03133 Axis name (relative coordinate) for current

position display

03134 Axis display order on workpiece coordinate

system screen and workpiece shift screen

03140 Display color for tool post name

03141 Name of the path (first character)

2-path

L L

control

03147 Name of the path (seventh character)

03151 Number of the axis for which the first load

meter for the servo motor is used

PRM

3111#5

L L

03158 Number of the axis for which the eighth load

meter for servo motor is used

03163 Time required to smooth the spindle load meter

readings [32 msec]
