8. ALARM LIST

495

8.1.2 Background edit alarms (BP/S alarm)

No. Message Contents

??? BP/S alarm BP/S alarm occurs in the same number as

the P/S alarm that occurs in ordinary pro-

gram edit. (ALM70– 74, 85–87, etc.)

140 BP/S alarm It was attempted to select or delete in the

background a program being selected in

the foreground. Use background editing

correctly.

NOTE Alarm in background edit is displayed in the key input line of the

background edit screen instead of the ordinary alarm screen and

is resettable by any of the MDI key operation.

8.1.3 Absolute pulse coder (APC) alarms

No. Message Contents

300 APC Alarm : nth–axis origin

return

Manual reference position return is re-

quired for the nth–axis (n=1 to 8).

301 APC alarm: nth–axis

communication

nth–axis (n=1 to 8) APC communication er-

ror. Failure in data transmission. Possible

causes include a faulty APC, cable, or ser-

vo interface module.

302 APC alarm: nth–axis over

time

nth–axis (n=1 to 8) APC overtime error.

Failure in data transmission. Possible

causes include a faulty APC, cable, or ser-

vo interface module.

303 APC alarm: nth–axis framing nth–axis (n=1 to 8) APC framing error. Fail-

ure in data transmission. Possible causes

include a faulty APC, cable, or servo inter-

face module.

304 APC alarm: nth–axis parity nth–axis (n=1 to 8) APC parity error. Fail-

ure in data transmission. Possible causes

include a faulty APC, cable, or servo inter-

face module.

305 APC alarm: nth–axis pulse

error

nth–axis (n=1 to 8) APC pulse error alarm.

APC alarm. APC or cable may be faulty.

306 APC alarm: nth–axis battery

voltage 0

nth–axis (n=1 to 8) APC battery voltage

has decreased to a low level so that the

data cannot be held. APC alarm. Battery or

cable may be faulty.

307 APC alarm: nth–axis battery

low 1

nth–axis (n=1 to 8) axis APC battery volt-

age reaches a level where the battery must

be renewed. APC alarm. Replace the bat-

tery.

308 APC alarm: nth–axis battery

low 2

nth–axis (n=1 to 8) APC battery voltage

has reached a level where the battery must

be renewed (including when power is OFF).

APC alarm .Replace battery.

309 APC ALARM:

n AXIS ZRN IMPOSSIBL

Return to the origin has been attempted

without first rotating the motor one or more

times. Before returning to the origin, rotate

the motor one or more times then turn off

the power.
