6. HARDWARE

213

D LED display transition at power–up

NO.

LED display NC Status

1 STATUS:jjjj Power off

2 STATUS:JJJJ Startup status immediately after power is

turned on

3 STATUS:jJJJ RAM initialized

4 STATUS:JjJJ Software ID set; keys initialized

5 STATUS:jjJJ Waiting for completion of software initializa-

tion 1

6 STATUS:JJjJ Waiting for completion of software initializa-

tion 2

7 STATUS:jJjJ Position coder initialized, etc.

8 STATUS:jJJj Waiting for digital servo initialization

9 STATUS:Jjjj Initialization completed (steady state)

J : ON j : OFF

The STATUS LEDs are green.

D LED display when an error occurs

LED display

Description

ALM:jJj System failure occurred.

The software detects the error and stops the system.

ALM:JJj Error in Local bus on the loader control board occurred.

ALM:jjJ System emergency occurred. Hardware detects the

error.

ALM:jJJ SRAM parity error on the loader control board oc-

curred.

J : ON j : OFF

The ALARM LEDs are red.

NOTE When two or more error occur simultaneously, the LED display

shows the state of low side on the table above.
