13. DIAGNOSIS INFORMATION

779

13.2.22 Display of diagnostic data related to rigid tapping

(DGN450 – 457)

450

Spindle position error during rigid tapping [Detection unit]

DGN

451

Spindle distribution during rigid tapping [Detection unit]

DGN

454

Accumulated spindle distribution during rigid tapping [Detection unit]

DGN

455

Instantaneous difference for the move command, calculated in

terms of the spindle,during rigid tapping

(signed, accumulated value) [Detection unit]

DGN

456

Instantaneous difference for the travel error, calculated in terms of

the spindle, during rigid tapping (signed) [Detection unit]

DGN

457

Width of synchronization error during rigid tapping

(maximum value) [Detection unit]

DGN

13.2.23 Status of the spindle polygon synchronization mode

(DGN470 – 478)

#6 #5 #4 #3 #2 #1 #0

470

SC0

DGN

LGE SCF PST SPL

SPL : Spindle polygon synchronization is in progress.

PST : Spindle polygon synchronization mode is starting.

#2 : Spindle polygon synchronization mode is being released.

#3 : The spindle speed is being changed in spindle polygon

synchronization mode.

SCF : The spindle speed has been changed in spindle polygon

synchronization mode.

#5 : Not used

LGE : In spindle polygon synchronization mode, the two spindles have

different loop gains.

SC0 : In spindle polygon synchronization mode, the specified speed is

zero.

#6 #5 #4 #3 #2 #1 #0

471

NPQ

DGN

PQE NSP SUO QCL PCL

#0 to #3Cause of ALM5018

ALM5018 can be cleared by issuing a reset. The cause

indication is retained until the cause is removed or until polygon

synchronization mode is released.

#4 to #7Cause of ALM218

If ALM218 occurs, polygon synchronization mode is released.

The cause indication, however, is retained until ALM218 is

cleared by issuing a reset.

#0 : The speed specified for spindle polygon synchronization is too

low. (The unit speed becomes 0 for internal operations.)

PCL : The first spindle (master axis in polygon synchronization) is

clamped.
