8.3 Alarms Indicated on the Screen of the Power Mate CNC Manag-

er (FANUC Servo Motor Amplifier β Series (I/O Link Option))

544

D I/O link alarm

No.

LED

display

Description Countermeasure

–

A FANUC I/O Link error

occurred. A servo amplifier

unit connected to the line

was turned off.

Turn off the power to all units

connected to the line. Then,

turn on the slave devices,

followed by the master

device.

D No LED display

No.

LED

display

Description Countermeasure

–

indicators lit

The control circuit is not

operating normally.

(1) Check the 24–VDC

control supply voltage.

If the voltage is low,

increase the voltage to

an appropriate level.

(2) Check whether a fuse in

the servo amplifier unit

has blown. If a blown

fuse is found, replace it.

If (1) and (2) are not the

cause, replace the servo

amplifier.
