15.4 Data Sampling for Storage Type

Waveform Diagnosis

814

2Press the

SYSTEM

function key, then select the waveform diagnosis

(memory data) screen.

3 Open the write protect switch of the Cassette or Card.

4 Press the soft keys [W.MEM],

, [PUNCH] and [EXEC] soft keys,

in this order.

Specify a file number at the end.

The file name WAVE DIAGNOS is assigned.

If the Cassette or Card used as the output destination already contains

a file having the same name as that specified, ALM086 is issued. To a

Cassette or Card, only one file of waveform diagnosis data of storage

type can be output. When output to a Cassette or Card containing

unnecessary storage type waveform diagnosis data is needed, delete

the file having the same name from the Cassette or Card beforehand.

Deleting a file is described later.

(iii) Displaying the directory of a Cassette or Card

The directory of a Cassette or Card can be displayed by following the

procedure below.

1 Set EDIT mode.

2Press the

PROG

function key, then select the program screen.

3 Press

. Then press [FLOPPY].

4 Press the page change key

PAGE

In this way, the directory is displayed.

(iv) Deleting a file from a Cassette or Card

A file can be deleted from a Cassette or Card by following the procedure

below.

1 Set EDIT mode.

2Press the

PROG

function key, then select the program screen.

3 Open the write protect switch of the Cassette or Card.

4 Press [FLOPPY].

5 Press [DELETE].

6 Type in a file number, then press [F SET].

7 Press [EXEC].

The file having the specified file number is deleted. After the file is

deleted, all subsequent file numbers are decremented by 1.

NOTE The floppy directory display function is optional.
