7. PARAMETERS

277

01404 Helical interpolation, reference position return

#0 HFC : The feedrate for helical interpolation is:

clamped along an arc and linear axis (0)/along

an arc and linear axis (1)

#1 DLF : After a reference position has been

established, a manual reference position return

operation is performed at the rapid traverse

rate (PRM1420) (0)/at the manual rapid

traverse rate (PRM1424) (1).

#2 F8A : With inch input, Valid data range for an F

command in feed per minute mode 9600

deg/min (0)/24000 deg/min (1)

#3 FRV : For inch input, the valid range of the feedrate

specified for feed per revolution is: F9.999999

inches per revolution (0)/F50.000000 inches

per revolution (1)

#5 EDR : The external deceleration speed in liner

interpolation type positioning is set in,

PRM1426(0)/PRM1427, for the first axis(1)

#7 FC0 : If a cutting block with a feedrate (F command)

of 0 is specified in automatic operation, ALM11

alarm is issued, and the block is not executed

(0)/the block is executed at a feedrate of 0 (1)

PRM1422,

1430

T series

01408 Feedrate of rotation axis <Axis>

#0 RFD : The feedrate about a rotation axis is controlled,

in the usual method(0)/by converting the

rotation speed about the rotation axis into the

travel speed on the circumference of a virtual

circle(1) (Set the radius of the virtual circle in

PRM1465.)

M series

01410 Dry run rate (feedrate of jog override is 100%)

The jog feedrate for manual linear or circular

interpolation [mm/min]

01411 Cutting feedrate in the automatic mode at

power-on [mm/min]

M series

01414 Feedrate for reverse movement by the retrace

function [mm/min]

M series

0: Pro-

grammed

command

01420 Rapid traverse rate for each axis

(Rapid traverse override is 100%) [mm/min]

<Axis>

01421 F0 rate of rapid traverse override for each axis

[mm/min]

<Axis>

01422 Maximum cutting feedrate [mm/min] PRM1430

01423 Manual continuous feedrate for each axis (jog

feedrate) [mm/min]

<Axis>

01424 Manual rapid traverse rate for each axis

If 0 is set, the rate set in PRM1420 is assumed

[mm/min]

<Axis>

PRM1420
