8.1 Alarms Displayed on NC Screen

478

No. ContentsMessage

200 ILLEGAL S CODE

COMMAND

In the rigid tap, an S value is out of the

range or is not specified. Modify the pro-

gram.

201 FEEDRATE NOT FOUND IN

RIGID TAP

In the rigid tap, no F value is specified. Cor-

rect the program.

202 POSITION LSI OVERFLOW In the rigid tap, spindle distribution value is

too large.

203 PROGRAM MISS AT RIGID

TAPPING

In the rigid tap, position for a rigid M code

(M29) or an S command is incorrect.

Modify the program.

204 ILLEGAL AXIS OPERATION In the rigid tap, an axis movement is speci-

fied between the rigid M code (M29) block

and G84 or G74 for M series (G84 or G88

for T series) block. Modify the program.

205 RIGID MODE DI SIGNAL

OFF

1. Although a rigid M code (M29) is speci-

fied in rigid tapping, the rigid mode DI

signal <G61#0> is not ON during

execution of the G84 (G88) block.

2. In a system with the multi–spindle op-

tion, the spindle used for rigid tapping

is not selected (by DI signal <G27#0,

#1>, or <G61#4, #5>).

Check the PMC ladder diagram to find the

reason why the DI signal is not turned on.

206 CAN NOT CHANGE PLANE

(M series)

Plane changeover was instructed in the rig-

id mode. Correct the program.

207 RIGID DATA MISMATCH The specified distance was too short or too

long in rigid tapping.

210 CAN NOT COMAND

M198/M199

1. The execution of an M198 or M99 com-

mand was attempted during scheduled

operation. Alternatively, the execution

of an M198 command was attempted

during DNC operation. Correct the pro-

gram.

2. The execution of an M99 command

was attempted by an interrupt macro

during pocket machining in a multiple

repetitive canned cycle. (T series)

211 G31 (HIGH) NOT ALLOWED

IN G99

(T series)

G31 is commanded in the per revolution

command when the high–speed skip op-

tion is provided. Modify the program.

ILLEGAL PLANE SELECT

(M series)

The arbitrary angle chamfering or a corner

R is commanded or the plane including an

additional axis. Correct the program.

212

ILLEGAL PLANE SELECT

(T series)

The direct drawing dimensions program-

ming is commanded for the plane other

than the Z–X plane. Correct the program.
