Series 16i/18i/21i/160i/180i/210i/160is/180is/210is - Model B Operation and maintenance handbook Page 48

Operation and maintenance handbook

Page of 992

/ 992

1. SCREEN DISPLAY AND OPERATION

1.3 Screen Operation Associated with

POS

1.3.1 Displaying the position using absolute coordinates

(a) Press soft key [ABS].

ABS

[][][][][]

REL ALL HNDL OPRT

ACTUAL POSITION (RELATIVE) O1000 N00010

Program number

Sequence

number

X 123.456

Y 363.233

Z 0.000

PART COUNT 5

RUN TIME 0H15M CYCLE TIME 0H 0M38S

ACT.F 3000 MM/M S 0 T0000

MEM STRT MTN*** 09:06:35

PRM6711

Time from

when the OP

signal is

turned off

(One machin-

ing cycle)

PRM3105#2 (DPS)=1

Inches/min is used when

values are input in inches.

PRM3105#0 (DPF)=1

Option

(displaying the number of parts and the operation time)

(b) Operation

Soft key [(OPRT)] [PTSPRE] [EXEC]

[RUNPRE] [EXEC]

PRM3115#0 (NDP) : 0: The current position is displayed for each

axis.

1: The current position is not displayed for each

axis.

PRM6700#0 (PCM) : The total number of machined parts and the

number of machined parts are incremented when

the following M codes are specified.

0: M02, M03, and the M codes specified with

PRM6710

1: The M codes specified with PRM6710

PRM6710: M code that counts the total number of machined parts

and the number of machined parts in the current

operation

PRM6711: Number of machined parts

PRM6751: Operation time (integrated time value during automatic

operation) [ms]

PRM6752: Operation time (integrated time value during automatic

operation) [min]

NOTE Hours and minutes are displayed on the screen.

PRM6757: Operation time (integrated value in one automatic

operation) [ms]

PRM6758: Operation time (integrated value in one automatic

operation) [min]

NOTE Hours, minutes, and seconds are displayed on

the screen.
