8.2 Alarms Displayed on the PMC Screen

524

Alarm number Contents

Faulty location/

corrective action

LBL FOR JMPC NOT

FOUND

If JMPC is unnecessary, re-

move it. If LBL is missing,

add it in proper position:

JMPC jumps into level 2. If

it should be JMPB or JMP,

correct it.

Can not find proper LBL for

JMPC.

LBL FOR JMPC IN

BAD LEVEL

JMPC is used to jump from

a subprogram to level 2. If

the JMPC is unnecessary,

remove it. If another LBL of

same L–address that the

JMPC is intended to jump

exists in the subprogram,

assign different L–address

to these two LBLs. If it

should be JMPB or JMP,

correct it.

Destination of JMPC is not

level 2.

JMPC INTO COM LBL for JMPC must be lo-

cated out of any COM and

COME pair. If the JMPC is

unnecessary, remove it. If

the LBL is located wrong,

move it to correct position. If

the L–address of JMPC is

wrong, correct it.

JMPC jumps to LBL be-

tween COM and COME.

JMPE WITHOUT

JMP

If JMP is missing, add it in

proper position. If the JMPE

is unnecessary, remove it.

There is no JMP that corre-

sponds to this JMPE.

TOO MANY LBL Remove unnecessary

LBLs. If this error still oc-

curs, adjust the construc-

tion of program to use less

LBLs.

There are too many LBLs.

DUPLICATE LBL If some of these LBLs are

unnecessary, remove them.

If all of these LBLs is neces-

sary, assign other L–ad-

dresses to them to make all

LBLs unique.

Same L–address is used in

plural LBLs.

OVERLAPPED SP If SP is missing, add it in

proper position. If the SPE

is unnecessary, remove it.

There is no SP that corre-

sponds to this SPE.

SPE WITHOUT SP If SP is missing, add it in

proper position. If the SPE

is unnecessary, remove it.

There is no SP that corre-

sponds to this SPE.

END IN SP If SPE is missing, add it in

proper position. If END is in

wrong place, move it to

proper position.

END is found between SP

and SPE.

DUPLICATE P

ADDRESS

If some of these SPs are un-

necessary, remove them. If

all of these SPs is neces-

sary, assign other P–ad-

dresses to them to make all

SPs unique.

Same P–address is used in

plural SPs.
