16. DIGITAL SERVO

819

Motor model α40/FAN α40/2000 α65/2000 α100/

2000

α150/

2000

Motor

specification

0158 0157 0331 0332 0333

Motor type No. 29 30 39 40 41

Motor model α300/1200 α300/2000 α400/1200 α400/2000

Motor

specification

0135 0137 0136 0138

Motor type No. 113 115 114 116

- αL series servo motor

Motor model αL3/3000 αL6/3000 αL9/3000 αL25/

3000

αL50/

3000

Motor

specification

0561 0562 0564 0571 0572

Motor type No. 68 69 70 50 60

- αC series servo motor

Motor model αC3/2000 αC6/2000 αC12/2000 αC22/1500

Motor

specification

0121 0126 0141 0145

Motor type No. 7 8 9 10

- α(HV) series servo motor

Motor model α3HV α6HV α12HV α22HV α30HV α40HV

Motor

specification

0171 0172 0176 0177 0178 0179

Motor type No. 1 2 3 102 103 118

Motor model α1000HV α22HV α30HV

Motor

specification

0131 0177 0178

Motor type No. 117 4 5

40–A driving 40–A driving

- αM series servo motor

Motor model αM2/

3000

αM2.5/

3000

αM3/

3000

αM6/

3000

αM9/

3000

Motor

specification

0376 0377 0161 0162 0163

Motor type No. 98 99 24 25 26

Motor model αM22/3000 αM30/3000 αM40/

3000FAN

αM40/3000

Motor

specification

0165 0166 0170 0170

Motor type No. 100 101 108 110

360–A driving 130–A driving
