8. ALARM LIST

535

8.3.2 Alarms of the FANUC servo motor amplifier β series

(I/O link option)

An alarm issued on the FANUC servo motor amplifier β series (I/O

Link Option) (hereinafter referred to as the “I/O Link β Amplifier”)

can be checked with the power pate CNC manager.

Classification of alarms

The alarms of the I/O Link β Amplifier are classified as described below.

Number

Alarm type

000 to 299 Program or setting alarm

300 to 399, 401 Pulse coder alarm

400 to 499 (except 401) Servo alarm

500 to 599 Overtravel alarm

– System alarm or I/O Link alarm

Alarm details

The alarm details of the I/O Link β Amplifier are as indicated below. These

alarms can be checked using the method below.

D Number: Alarm screen of the power mate CNC manager

D LED indication: LED on the servo amplifier

D Program or setting alarms (PS alarms)

No.

LED

display

Description Countermeasure

000

A parameter that requires

power–down has been spe-

cified.

Turn the power off, then

back on.

011

The specified feedrate is

zero.

Check the feedrate parame-

ter(*) specified with a func-

tion code.

013

The specified feedrate

(maximum feedrate) is zero.

Check the value of parame-

ter(*) 43, which indicates the

maximum feedrate that can

be specified.

070

More than 32 blocks have

been registered for a buffer-

ing operation.

Reduce the number of regis-

tered blocks to 32.

090

Reference position setting

cannot be executed nor-

mally.

Move the tool in the direc-

tion of reference position

return in jog mode at a

speed that causes the servo

position error to exceed 128.

Then, specify another refer-

ence position setting.

093

A first to third reference

position return cannot be

executed because the refer-

ence position has not yet

been established.

Set the reference position.

224

The reference position has

not yet been established.

This occurs only when the

ZRTN bit of parameter

No.001 is set to 0.

Set the reference position.
