7.2 Parameter List

398

49) For tool life management

06800

Tool life management

#0 GS1 : Setting the combination of the number of tool

life groups and the number of tools

#1 GS2 : Setting the combination of the number of tool

life groups and the number of tools

The values on the lower row in the table apply

when the 512–(M series) or 128–(T series)

–tool–life–management–group option is

provided.

#2 LTM : Tool life is specified by the number of times (0)

/by time (1)

#3 SIG : Not input the group number using a tool group

signal during tool skip (0)/input the group

number (1)

#4 GRS : Data clear during the input of tool exchange

reset signal clears only the execution data of

specified groups (0)/the execution data of all

entered groups (1)

#5 SNG : At the input of a tool skip signal when tools

other than those under tool life management

are selected, skips a tool that is used last or

specified (0)/ignores a tool skip signal (1)

#6 IGI : Tool back number is not ignored (0)/ignored (1)

#7 M6T : T code in the same block as M06 is judged as

a back number (0)/as a next tool group

command (1)

GS2 GS1

M series

Group

count

Tool

count

1–16

1–64

1–16

1–32

Group

count

Tool

count

1–16

1–32

T series

011–32

1–28

1–8

1–16

1–32

1–8

1–16

101–64

1–256

1–4

1–8

1–64

1–4

1–8

111–128

1–512

1–2

1–4

1–16

1–128

1–16

1–4
