1. SCREEN DISPLAY AND OPERATION

1.4.3 Screen displaying the contents of the program currently

running

(a) Press soft key [CURRNT].

This operation is unnecessary for the 9.5”/10.4” display unit.

PRGRM

[][][][][]

CHECK CURRNT NEXT (OPRT)

PROGRAM O2000 N00130

>_ S 0 T0000

MEM STRT *** 16:05:59

Modal

information

(CURRNT) (MODAL)

G01 X 17.500 G67 G01 F 2000

G17 F 2000 G54 G17

G41 H 2 G64 G91

G80 G69 G22

G15 G94

G40.1 G21 H 2 D

G25 G41

G49 T

G80

G98 S

G50

Block data being processed

Data with a decimal point

corresponds to the absolute

command.

Data without a decimal point

corresponds to the incre-

mental command.

1.4.4 Screen displaying the current and next blocks

(a) Press soft key [NEXT].

PRGRM

[][][][][]

CHECK CURRNT NEXT (OPRT)

PROGRAM O2000 N00130

>_ S 0 T0000

MEM STRT *** 16:05:59

(CURRNT) (NEXT)

G01 X 17.500 G39 I –17.500

G17 F 2000 G42

G41 H 2

G80

Note)

Data with a decimal point corresponds

to the absolute command. Data without

a decimal point corresponds to the in-

cremental command.

Contents of the program

read into the buffer.

Nothing is displayed for

single block operation.
