Series 16i/18i/21i/160i/180i/210i/160is/180is/210is - Model B Operation and maintenance handbook Page 451

Operation and maintenance handbook

Page of 992

/ 992

7.2 Parameter List

418

62) For attitude control

07941

Attitude control M series

#0 INT : Interaction control is enabled (0)/disabled (1)

#1 ATT : Attitude control is enabled (0)/disabled (1)

#3 MIA : When attitude control B is used, G53 operation

is placed in tip fix mode (0)/independent axis

mode (1)

#4 RNC : According to a rotation made on the α axis and

β axis in manual reference position return

operation, the X, Y, and Z coordinates

(absolute) and relative coordinates are:

updated (0)/not updated (1)

07942 Attitude control M series

#0 PA4 : This parameter must be set when rotation

about the α axis is performed in the same

direction (0)/in the opposite direction (1)

#1 PA5 : This parameter must be set when rotation

about the β axis is performed in the same

direction (0)/in the opposite direction (1)

07943 Interaction control M series

#0 TGC : Interaction control on the α axis is exercised

with the polarity opposite to that of the β axis

command (0)/with the same polarity as that of

the β axis command (1)

07950 α axis machine zero–degree point offset

[0.01deg]

M series

07951 β axis machine zero–degree point offset

[0.01deg]

M series

07952 Upper limit on α axis machining speed

[deg/min]

M series

07953 Upper limit on β axis machining speed

[deg/min]

M series

07954 Length of the first arm M series

07955 Length of the second arm M series

07956 Number of α–axis interaction gears

07957 Number of β–axis interaction gears
