8.2 Alarms Displayed on the PMC Screen

532

8.2.7 Error messages (for I/O)

Message

Faulty location/

corrective action

Contents

PROGRAM

NOTHING

Write a ladder program to the

flash ROM.

There is no program on flash

ROM.

ERASE ERROR Replacement is required. Flash ROM is abnormal.

WRITE ERROR

Ask FANUC Service Repre-

sentative for replacement.

READ ERROR

sentative for replacement.

ANOTHER

USED

Do not use the flash ROM for

other than the PMC.

Flash ROM is used by other

than PMC.

NOT EMG

STOP

Set the emergency stop

state.

The CNC is not in the emer-

gency stop state.

NO OPTION An option is required. No option is specified.

IMPOSSIBLE

WRITE

(SIZE OVER)

NO SPACE

Try the condense function.

(EDIT/CLEAR screen) If the

same phenomenon is still

observed, the flash ROM

size must be enlarged.

The sequence program is

larger than the flash ROM

size. (At write)

RAM must be enlarged. The sequence program to be

read is larger than the RAM

size. (At read)

I/O OPEN

ERROR nn

Check whether RS–232C is

used by other than PMC.

On the online setting screen,

check that “NOT USE” is in-

dicated for RS–232C.

nn=–1 : RS–232C is used by

other than PMC.

Check whether channel set-

ting, connection, baud rate,

and other settings are cor-

rect.

nn=6: The RS–232C option

is not found.

nn=20: RS–232C connec-

tion is incorrect.

⋅

I/O WRITE

ERROR nn

Check whether channel set-

ting, connection, baud rate,

and other settings are cor-

rect.

nn=20 : RS–232C connec-

tion is incorrect.

⋅

Check whether the cable is

broken.

nn=22 : Communication

cannot be performed cor-

rectly.

⋅

I/O READ

ERROR nn

Check whether channel set-

ting, connection, baud rate,

and other settings are cor-

rect.

nn=20 : RS–232C connec-

tion is incorrect.

Check whether the cable is

broken.

nn=22 : Communication

cannot be performed cor-

rectly.

ADDRESS IS

OUT OF

RANGE(xxxxxx)

Transfer data held in the

RAM area.

Data for other than the PMC

debugging RAM area was

transferred.

xxxxxx : Indicates the trans-

fer address.

DATA ERROR Check the cable and setting

(speed).

Illegal data was read.

PROGRAM

DATA ERROR

Check the alarm on the

alarm screen.

An attempt was made to out-

put data, but the data was il-

legal.
