19.1 Inputting/Outputting Data

894

5. After the parameter has been inputted, turn off power and turn it on.

6. ALM300 is issued if the system employs an absolute pulse coder. In

such a case, perform reference position return again.

19.1.3.2 Inputting PMC parameters

Set the emergency stop state.

1. Turn off (KEY4=1) the program protect key.

2. Press

SETTING

OFFSET

key and soft key [SETING] to select the SETTING screen.

3. Confirm that PARAMETER WRITE=1.

4. Press

SYSTEM

key and soft key [PMC].

5. Press soft key [PMCPRM] and soft key [KEEPRL].

6. Set the cursor to K900 (on the SB7) or K17 (on the SA1) and set bit 1

to 1.

0 0 0 0 0 0 1 0

INPUT

7. Press

key and key.

8. Press soft key [I/O] and set the parameters required for I/O.

Item selection cursor displays the next item after an item is set.

9. In CHANNEL item , press

INPUT

to select channel 1.

10. In DEVICE item, press [FDCAS] key to select the floppy cassette.

11. In FUNCTION item, press soft key [READ] to input data

12. Press soft key [EXECT] and the PMC parameters are started to be

input.

13. After data has been read, turn off power and turn it on.

19.1.3.3 Inputting pitch error compensation amount

1. Release the emergency stop and select EDIT mode.

2. Confirm that PARAMETER WRITE=1 on the setting screen.

3. Press

PROG

key and soft key [PRGRM] to display program contents.

4. Press soft key [(OPRT)],

, [F SRH], and

[EXEC] to select the

pitch error compensation file.

5. Press

SYSTEM

key several times, soft key [PARAM], and [PITCH]

to select the screen for pitch error compensation amount.

6. Press soft key [(OPRT)] and key.

7. Press soft key [READ] and [EXEC], then the pitch error compensation

amount is started to be input.

8. After data has been input, press

SETTING

OFFSET

key twice to display the

SETTING screen and return the PARAMETER WRITE to 0.
