6. HARDWARE

187

Name RemarksIDDrawing

number

DRAM module

(4MB)

A20B–3900–0042 85 For optional board

PMC–SE board A20B–8100–0150 1xCD

C language board A20B–8100–0261 0xCD

Serial communica-

tion board A

A20B–8100–0262 2xCD Remote buffer/DNC2

Serial communica-

tion board B

A20B–8100–0263 3xCD DNC1

Symbol CAPi T

board

A20B–8100–0264 4xCD

Sub CPU board A20B–8002–0190 1xCE

RISC board A20B–8002–0040 xxCA

Data server board A20B–8100–0271 3xDB

Fast data server

board

A20B–8100–0770 0x8E

Data server

ADD–ON board

A20B–2002–0960 –

Loader control

board

A20B–8100–0830 1xD3

HSSB interface

board

A20B–8001–0641 ExAA

I/O Link–II board A20B–8100–0250 0x95

PROFIBUS board A20B–8100–0430 0xBB Master function

ADD–ON board A20B–2100–0430 – Slave function

Ethernet board A20B–8100–0271 3xDB

Fast Ethernet

board

A20B–8100–0770 0x8E

DeviceNet board A20B–8001–0880 1xF3

Backpanel (2 slots) A20B–2003–0150 –

Backpanel (3 slots) A20B–2003–0230 –

Backpanel (4 slots) A20B–2003–0140 –

Inverter PCB

(For 9.5I/7.2I

monochrome LCD)

A20B–8100–0710 –

Inverter PCB

(For 10.4I color

LCD)

A20B–8001–0920 –

Inverter PCB

(For 8.4I color

LCD)

A20B–8001–0922 –

PC–side HSSB in-

terface board

(2CH, applicable to

ISA bus)

A20B–8001–0582 –

PC–side HSSB in-

terface board

(1CH, applicable to

ISA bus)

A20B–8001–0583 –
