9. SIGNAL LIST (X/Y, G/F)

601

#7 #6 #5 #4 #3 #2 #1 #0

F132

EM28A EM24A EM22A EM21A EM18A EM14A EM12A EM11A

F133

EBSYB EOTNB EOTPB EGENB EDENB EIALB ECKZB EINPB

F134

EABUFB EMFB

F135

EM28B EM24B EM22B EM21B EM18B EM14B EM12B EM11B

F136

EBSYC EOTNC EOTPC EGENC EDENC EIALC ECKZC EINPC

F137

EABUFC EMFC

F138

EM28C EM24C EM22C EM21C EM18C EM14C EM12C EM11C

F139

EBSYD EOTND EOTPD EGEND EDEND EIALD ECKZD EINPD

F140

EABUFD EMFD

F141

EM28D EM24D EM22D EM21D EM18D EM14D EM12D EM11D

F142

EM48A EM44A EM42A EM41A EM38A EM34A EM32A EM31A

F145

EM48B EM44B EM42B EM41B EM38B EM34B EM32B EM31B

F148

EM48C EM44C EM42C EM41C EM38C EM34C EM32C EM31C

F151

EM48D EM44D EM42D EM41D EM38D EM34D EM32D EM31D

F168

ORARC TLMC LDT2C LDT1C SARC SDTC SSTC ALMC

F169

MORA2C MORA1C PORA2C SLVSC RCFNC RCHPC CFINC CHPC

F170

EXOFC SORENC

MSOVRC

INCSTC PC1DEC

F172

PBATL PBATZ

F177

EDGN EPARM EVAR EPRG EWTIO ESTPIO ERDIO IOLNK

F178

SRLNO3 SRLNO2 SRLNO1 SRLNO0

F180

CLRCH8 CLRCH7 CLRCH6 CLRCH5 CLRCH4 CLRCH3 CLRCH2 CLRCH1

F182

EACNT8 EACNT7 EACNT6 EACNT5 EACNT4 EACNT3 EACNT2 EACNT1

F197

MFSYND MFSYNC MFSYNB MFSYNA

F208

EGBM8 EGBM7

EGBM6 EGBM5 EGBM4

EGBM3 EGBM2 EGBM1
