15.1 Waveform Diagnostic Parameter Screen

806

Data No. Description Units

00 Does not display a waveform. –

0n Servo error (8 ms) for the n–th axis

(positional deviation)

Pulses

(detection units)

1n Pulse distribution for the n–th axis

(move command)

Pulses

(input increments)

2n Torque for the n–th axis (actual cur-

rent)

% (relative to maximum

current)

3n Servo error (2 ms) for the n–th axis

(positional deviation)

Pulses

(detection units)

5n Actual speed for the n–th axis min

–1

6n Command current for the n–th axis % (relative to maximum

current)

7n Thermal simulation data for the

n–th axis

% (OVC alarm ratio)

90 Composite speed for the first, se-

cond, and third axes

Pulses

(input increments)

99 On/off state of a machine signal

specified with a signal address

None

10n Actual spindle speed for the n–th

axis

% (relative to maximum

rotation speed)

11n Load meter for the n–th spindle % (relative to maximum

output)

161 Difference in position error calcu-

lated on the spindle basis

Pulses (detection unit)

(5) Data units: Weight of data when 1 is specified. The data units are

automatically specified for each data item and need not be set unless the

units must be changed for some reason.

[Valid data range] 1 to 1000

[Unit] 0.001

(6) Signal address: PMC address and bit number. Set in the same way as

that for trigger, when the data number is 99.
