1. Fanuc
  2. Series 16i/18i/21i/160i/180i/210i/160is/180is/210is - Model B

Series 16i/18i/21i/160i/180i/210i/160is/180is/210is - Model B Operation and maintenance handbook Page 488

Operation and maintenance handbook
7. PARAMETERS
455
14944 Maximum point on the first axis of rectangle 2
in group B [Increment system]
14945 Minimum point on the first axis of rectangle 2 in
group B [Increment system]
14946 Maximum point on the second axis of rectangle
2 in group B [Increment system]
14947 Minimum point on the second axis of rectangle
2 in group B [Increment system]
14948 Maximum point on the first axis of rectangle 3
in group B [Increment system]
14949 Minimum point on the first axis of rectangle 3 in
group B [Increment system]
14950 Maximum point on the second axis of rectangle
3 in group B [Increment system]
14951 Minimum point on the second axis of rectangle
3 in group B [Increment system]
14952 Maximum point on the first axis of rectangle 4
in group B [Increment system]
14953 Minimum point on the first axis of rectangle 4 in
group B [Increment system]
14954 Maximum point on the second axis of rectangle
4 in group B [Increment system]
14955 Minimum point on the second axis of rectangle
4 in group B [Increment system]
14956 Center of rotation of the first axis for rotating
group B [Increment system]
14957 Center of rotation of the second axis for
rotating group B [Increment system]
14958 Reference rotation angle for the rotation axis in
group B [Increment system]
14960 Maximum point on the first axis of rectangle 1
in group C [Increment system]
14961 Minimum point on the first axis of rectangle 1 in
group C [Increment system]
14962 Maximum point on the second axis of rectangle
1 in group C [Increment system]
14963 Minimum point on the second axis of rectangle
1 in group C [Increment system]
14964 Maximum point on the first axis of rectangle 2
in group C [Increment system]
14965 Minimum point on the first axis of rectangle 2 in
group C [Increment system]
