7
7.2 Parameter List
290
01896 Number of gear teeth on the servo motor axis
side
01897 Number of gear teeth on the milling axis side
01902 FSSB Setting
#0 FMD : The FSSB setting mode is, automatic setting
mode (0)/manual setting 2 mode (1)
#1 ASE : When automatic setting mode is selected for
FSSB setting (when the FMD parameter (bit 0 of
parameter No.1902) is set to 0), automatic setting
is, not completed (0)/completed (1)
PRM
1902#0
01904 Using status of DSP <Axis>
#0 DSP : Two axes use one DSP (0)/one axis uses one
DSP (1)
01905 Type of servo interface <Axis>
#0 FSL : The type of interface used between the servo
amplifier and servo software is, fast type
(0)/slow type (1)
#4 IO1 : A first I/O module supporting FSSB is, not
used(0)/used(1)
#5 IO2 : A second I/O module supporting FSSB is, not
used(0)/used(1)
#6 PM1 : The first separate detector interface unit is, not
used (0)/used (1)
#7 PM2 : The second separate detector interface unit is,
not used (0)/used (1)
01910 Address conversion table value for slave 1
(ATR)
01911 Address conversion table value for slave 2
(ATR)
01912 Address conversion table value for slave 3
(ATR)
01913 Address conversion table value for slave 4
(ATR)
01914 Address conversion table value for slave 5
(ATR)
01915 Address conversion table value for slave 6
(ATR)
01916 Address conversion table value for slave 7
(ATR)
01917 Address conversion table value for slave 8
(ATR)
01918 Address conversion table value for slave 9
(ATR)
