8.2 Alarms Displayed on the PMC Screen

526

Alarm number Contents

Faulty location/

corrective action

NO WRITE COIL Add proper write coil. Write coil is necessary, but

is not found.

CALL/CALLU IN

BAD LEVEL

CALL/CALLU must be used

in Level 2 or in subpro-

grams. Do not use any other

places.

CALL/CALLU is used in

wrong place.

SP IN LEVEL3 If END3 is located wrong,

move it to correct position. If

the SP is unnecessary, re-

move it.

SP is found in level 3.

(3) Messages displayed during net editing of the PMC ladder diagram

editing

Alarm number

Faulty location/

corrective action

Contents

TOO MANY

FUNCTIONAL

INSTRUCTIONS IN

ONE NET

Only one functional instruc-

tion is allowed to constitute

a net. If necessary, divide

the net into plural nets.

Too many functional

instructions are in one net.

TOO LARGE NET Divide the net into plural

nets so that step number in

a net may become small.

Net is too large. When a net

is converted into the object,

the net exceeds 256 steps.

NO INPUT FOR

OPERATION

Coil without input, or coil

connected to output of func-

tional instruction that has no

output, causes this error. If

coil is not necessary, re-

move it. If necessary, con-

nect it to meaningful input.

No signal is provided for

logical operation.

OPERATION AFTER

FUNCTION IS

FORBIDDEN

Output of functional instruc-

tion can not be connected to

a contact, nor to conjunc-

tion with other signal that

will be implemented by log-

ical–or operation.

No logical operation with

functional instruction output

is permitted, except write

coils.

WRITE COIL IS

EXPECTED

Add proper write coil to the

net.

Write coil is expected, but

not found.

BAD COIL

LOCATION

Coil can be located only at

rightmost column. Any coil

located at other place must

be erased once, and place

necessary coils in correct

place.

Coil is located in bad posi-

tion.

SHORT CIRCUIT Find contact with terminals

connected by short circuit,

and correct connections.

Some contacts are con-

nected with short circuit.

FUNCTION AFTER

DIVERGENCE IS

FORBIDDEN

Functional instruction can

not be used in output sec-

tion of net. If necessary, di-

vide the net into plural nets.

Functional instruction is

used in output section of

net.

ALL COIL MUST

HAVE SAME INPUT

Left terminals of all coils in

a net must be connected to

same input point.

When a net contains more

than one coil, the coils

should not have any contact

beside them affects only of

the coils.
