19.4 LED Indication and Maintenance Operation of

the Stand–Alone Type Unit

938

19.4.2 Maintenance operation method

19.4.2.1 Operation before power–on

Before turning on the power, select a function number by using the rotary

switch. When the power is turned on after the selection with the rotary

switch, the number corresponding to the selected function number is

indicated on the LED. The indication blinks at intervals of about one second.

D Function Number

Each function is assigned a number. This number is called a function

number hereinafter in this manual. The function numbers that can be

selected with the rotary switch are listed below. Do not set the reserved

function numbers. (If a reserved function number is set, the system

operates as if function number 0 were selected. However, a function may be

added in the future.)

Function

number

Explanation

0 Normal state. After terminating maintenance operation, al-

ways set this number.

1 Reserved

2 Sets a device number for the display link function.

3 Reserved

4 Confirms a device number for the display link function.

5 Memory all clear

6 Reserved

7 Reserved

8 Saves battery backed–up main board data in a memory card

at a time.

9 Reserved

A Restores battery backed–up main board data from a memory

card at a time.

B Reserved

C Reserved

D Reserved

E Reserved

F Reserved
