8.1 Alarms Displayed on NC Screen

486

No. ContentsMessage

5068 G31 FORMAT ERROR

(M series)

The continuous high–speed skip com-

mand (G31 P90) has one of the following

errors:

1. The axis along which the tool is moved

is not specified.

2. More than one axis is specified as the

axis along which the tool is moved.

Alternatively, the EGB skip command

(G31.8) or continuous high–speed skip

command (G31.9) has one of the following

errors:

1. A move command is specified for the

EGB axis (workpiece axis).

2. More than one axis is specified.

3. P is not specified.

4. The specified Q value exceeds the al-

lowable range.

Correct the program.

5069 WHL–C:ILLEGA P–DATA

(M series)

The P data in selection of the grinding–

wheel wear compensation center is illegal.

5073 NO DECIMAL POINT No decimal point has been specified for an

address requiring a decimal point.

5074 ADDRESS DUPLICATION

ERROR

The same address has been specified two

or more times in a single block. Alternative-

ly, two or more G codes in the same group

have been specified in a single block.

5082 DATA SERVER ERROR This alarm is detailed on the data server

message screen.

5085 SMOOTH IPL ERROR 1 A block for specifying smooth interpolation

contains a syntax error.

5096 MISMATCH WAITING

M–CODE

(M series)

Different wait codes (M codes) were speci-

fied in HEAD1 and HEAD2.

Correct the program.

5110 NOT STOP POSITION

(G05.1 G1)

(M series)

An illegal G code was specified in AI con-

tour control mode.

A command was specified for the index

table indexing axis in AI control mode.

NOT STOP POSITION

(G05.1 G1)

(21i–M)

An illegal G code was specified in AI ad-

vanced previee control mode.

A command was specified for the index

table indexing axis in AI advanced previee

control mode.

5111 IMPROPER MODEL

G–CODE (G05.1 G1)

(M series)

An illegal G code is left modal when AI con-

tour control mode was specified.

IMPROPER MODEL

G–CODE (G05.1 G1)

(21i–M)

An illegal G code is left modal when AI ad-

vanced previee control mode was speci-

fied.

5112 G08 CAN NOT BE

COMMANDED (G05.1 G1)

(M series)

Advanced previee control (G08) was speci-

fied in AI contour control mode.

G08 CAN NOT BE

COMMANDED (G05.1 G1)

(21i–M)

Advanced previee control (G08) was speci-

fied in AI advanced previee control mode.
