Operation and maintenance handbook
7. PARAMETERS
447
12041 G code number for embedded macro
(eighth set)
12042 Program number for embedded macro
(eighth set)
12043 G code macro count for embedded macro
(eighth set)
12044 G code number for embedded macro
(ninth set)
12045 Program number for embedded macro
(ninth set)
12046 G code macro count for embedded macro
(ninth set)
12047 G code number for embedded macro
(tenth set)
12048 Program number for embedded macro
(tenth set)
12049 G code macro count for embedded macro
(tenth set)
Used to set G codes for embedded macros
(Example) When G code number = 100, program
number = 8000, and the number of G
codes = 5,
the G codes G100 to G104 correspond
to O8000 to O8004.
If multiple sets are used and a G code
duplication occurs, a younger set has
priority.
77) For high–speed position switch (2/2)
12201
Axis corresponding to the eleventh high–speed
position switch
PRM
8505#2–#7
12202 Axis corresponding to the twelfth high–speed
position switch
12203 Axis corresponding to the thirteenth
high–speed position switch
12204 Axis corresponding to the fourteenth
high–speed position switch
12205 Axis corresponding to the fifteenth high–speed
position switch
12206 Axis corresponding to the sixteenth high–speed
position switch
