7.2 Parameter List

338

04015 Output switching, orientation

#0 ORIENT : The orientation function is not provided (0)/

provided (1)

#1 SPLDMT: The spindle load monitor function is

disabled (0)/enabled (1).

#2 SPDSW : The output switching function is not

provided (0)/provided (1)

04016 One-rotation signal error detection function

#3 FFSMTH: The feed-forward smoothing function is

disabled (0)/enabled (1).

#4 CMTVL : Cs contour control setting (Usually 0.)

#5 RFCHK1: The Cs contour control one-rotation signal

error detection function is disabled (0)/

enabled (1).

#6 RFCHK2: The position coder one-rotation signal error

detection function is disabled (0)/enabled

(1).

#7 RFCHK3: In spindle orientation, spindle

synchronization, or rigid tapping reference

position return mode, the position coder

one-rotation signal is not detected again

(0)/detected again (1).

04017 One-rotation signal error detection function

#2 RFCHK4 : During normal rotation, the position coder

one-rotation signal error detection

function is disabled (0)/enabled (1).

#7 NRROEV : With an orientation command from the

stop state, the shortcut function is

disabled (0)/enabled (1).

04019 Cs contour control dead zone compensation,

automatic parameter setting

#0DTTMCS : Cs contour control dead zone

compensation is disabled (0)/enabled (1).

#2 SSTTRQ : When the speed is 0, speed clamping is

disabled (0)/enabled (1).

#4 SDTCHG : In output switching, the function for

switching at a speed detection level or

lower operates independently of speed

detection (0)/at the speed detection level

or lower (1).

#7 PRLOAD : Automatic parameter setting is not

performed (0)/performed (1).

04020 Maximum motor speed [min

–1

]

04021 Maximum speed when the Cs axis is controlled

[min

–1

]

04022 Speed arrival detection level [0.1%]

04023 Speed detection level [0.1%]

04024 Speed zero detection level [0.01%]
