7.2 Parameter List

408

53) For manual linear and circular functions

07160

Approach handle clamp feedrate

[Increment system]

When the

setting is

0, the

07161 Guidance handle clamp feedrate

[Increment system]

feedrate is

not

clamped.

54) For butt-type reference position setting

07181

First withdrawal distance in butt-type reference

position setting

PRM

1006#5

07182 Second withdrawal distance in butt-type

reference position setting

PRM

1006#5

07183 First butting feedrate in butt-type reference

position setting

07184 Second butting feedrate in butt-type reference

position setting

07185 Withdrawal feedrate (common to the first and

second butting operations) in butt-type

reference position setting

07186 Torque limit value in butt-type reference

position setting

55) For software operator’s panel

07200

Function selection

#0 OP1 : Mode selection is not performed on software

operator’s panel (0) /performed (1)

#1 OP2 : JOG feed axis selection is not performed on

software operator’s panel (0) / performed (1)

#2 OP3 : MPG’s axis selection is not performed on

software operator’s panel (0) / performed (1)

#3 OP4 : Override is not performed on software

operator’s panel (0) /performed (1)

#4 OP5 : BDT,SBK,MLK,DRN are not performed on

software operator’s panel (0) / performed (1)

#5 OP6 : Protect key is not performed on software

operator’s panel (0) / performed (1)

#6 OP7 : Feed hold is not performed on software

operator’s panel (0) / performed (1)

07201 General–purpose switch

#0 JPC : For the name of a general–purpose switch

function on the software operator’s panel, the

use of full–size characters is not allowed (0)/

allowed (1)

07210 Jog movement axis and its direction on

software operator’s panel °

07211 Jog movement axis and its direction on

software operator’s panel ±
