7.2 Parameter List

380

38) For custom macro

06000

Single block

#0 G67 : A G67 specified in modal call cancel mode

issues an alarm (0)/is ignored (1).

#1 MGO: When a GOTO statement is executed, a

high–speed branch to 20 sequence numbers

executed from the start of the program is, a

high–speed branch is not caused (0)/a

high–speed branch is caused (1)

#2 HMC : A custom macro is executed, at a normal

speed (0)/at a high–speed (1)

#3 V15 : The system variables for tool compensation

are the standard those used with FS16 (0)/

FS15 (1).

#4 HGO : When a GOTO statement is executed a

high–speed branch is not caused (0)/a

high–speed branch is caused (1)

#5 SBM : In the custom macro statement, the single

block stop is not valid (0)/valid (1)

#7 SBV : When execution is controlled with the system

variable #3003, single block stop in a macro

statement is, disabled (0)/enabled (1)

M series

PRM

6000#7

PRM

6000#5=0

06001 Variable initialization, T code call, PRINT

command

#1 PRT : When data is output using a DPRINT

command, outputs a space for reading zero

(0)/outputs no data (1)

#3 PV5 : The output macro variables are #500 and up

(0)/#100 and up and #500 and up (1).

#4 CRO : When ISO code is used in the B/D PRINT

mode, output only “LF” (0)/output “LF” and

“CR” (1)

#5 TCS : Custom macro is not called using a T code (0)/

called (1)

#6 CCV : Common variables #100 through #149 (to 199)

are cleared to “vacant” by reset (0)/not cleared

by reset (1)

#7 CLV : Local variables #1 through #33 are cleared to

“vacant” by reset (0)/not cleared by reset (1)

O9000
