7.2 Parameter List

364

27) For rigid tapping

05200

Rigid tapping

#0 G84 : M codes for rigid tapping mode command are,

used (0)/not used (1)

#1 VGR : Any gear ration between spindle and position

coder in rigid tapping is not used (0)/used (1)

#2 CRG : When a rigid mode cancel command is

specified, the rigid mode is not canceled before

RGTAP signal is set low (0)/canceled (1)

#3 SIG : When gears are changed for rigid tapping, the

use of SIND is not permitted (0)/permitted (1)

#4 DOV : Override during extraction in rigid tapping is

invalidated (0)/validated (1)

#5 PCP : In rigid tapping, a high-speed peck tapping

cycle is used (0)/not used (1)

#6 FHD : Feed hold and single block in rigid tapping are

validated (0)/invalidated (1)

#7 SRS : When multi-spindle control is used, the spindle

selection signal is G027.0 and G027.1 (0)/

G061.4 and G061.5 (1).

PRM5210

PRM3706,

5221 to

5234

PRM5211

M series

PRM5213

T series

05201 Rigid tapping

#0 NIZ : Rigid tapping smoothing processing is disabled

(0)/enabled (1).

#2 TDR : Cutting time constant in rigid tapping uses a

same parameter during cutting and extraction

(0)/not use a same parameter (1)

#3 OVU : The increment unit of the override PRM5211 is

1% (0)/ 10% (1)

#4 OV3 : Overriding by program is disabled (0)/enabled

(1)

M series

PRM5261

to 5264,

5271 to

5274

05202 Rigid tapping

#0 ORI : When rigid tapping is started, orientation is not

performed (0)/performed (1).

M series
