19.1 Inputting/Outputting Data

896

19.1.3.6 Inputting part programs

Confirm the following parameters. If the setting is different from the value

indicated by l, reset to the specified value only during this work.

(Change it in MDI mode).

#6 #5 #4 #3 #2 #1 #0

3201

NPE RAL

#1 (RAL) When programs are registered:

l 0 :All programs are registered.

1 :Only one program is registered.

#6 (NPE) When programs are registered in part program storage area,

M02,M30 and M99 are:

0 :regarded as the end of program.

l 1 :not regarded as the end of program.

#6 #5 #4 #3 #2 #1 #0

3202

NE9 NE8

#0 (NE8) l 0 :Programs of 8000s can be edited.

1 :Programs of 8000s are protected.

#4 (NE9) l 0 :Programs of 9000s can be edited.

1 :Programs of 9000s are protected.

#6 #5 #4 #3 #2 #1 #0

3204

P9E P8E

#3 (P8E) Editing of subprograms 80000000 to 89999999 is:

l 0 :Not inhibited

1 :Inhibited

NOTE This parameter is valid when the program number O 8–digit option

is selected.

#4 (P9E) Editing of subprograms 90000000 to 99999999 are:

l 0 :Not inhibited

1 :Inhibited

The following editing types become impossible.

NOTE This parameter is valid when the program number O 8–digit option

is selected.

1. Confirm that mode is EDIT mode.

2. Turn off the program protect (KEY3=1).

3. Press

PROG

key and press soft key [PRGRM] to select a part program

file.

4. Press soft key, [(OPRT)] and key.

5. Press soft key [READ] and [EXEC], then data input is started.
