9. SIGNAL LIST (X/Y, G/F)

587

Symbol

series

AddressSignal name

TLMA F045#6 f f

TLMB

Torque limit signal

F049#6 f f

TLMC

Torque limit signal

(serial spindle)

F168#6 f f

TLMD F266#6 f f

TLMHA G070#1 f f

TLMHB

Torque limit command

G074#1 f f

TLMHC

HIGH signal

(serial spindle)

G204#1 f f

TLMHD

(serial spindle)

G266#1 f f

TLMLA G070#0 f f

TLMLB

Torque limit command LOW

G074#0 f f

TLMLC

signal

(serial spindle)

G204#0 f f

TLMLD

(serial spindle)

G266#0 f f

TLNW New tool select signal F064#1 f f

TLRST Tool change reset signal G048#7 f f

TLRSTI Individual tool change reset

signal

G048#6 – f

TLSKP Tool skip signal G048#5 f f

TMRON General–purpose

integrating meter start

signal

G053#0 f f

TRACT Tool retraction mode signal F092#3 f f

TRESC Tool retraction signal G059#0 f f

TRQL1 to

TRQL8

Torque limit reached signal F114 f f

TRRTN Tool return signal G059#1 f f

TRSPS Tool return completion

signal

F092#5 f f

UI000 to UI015 Input signal for custom

macro

G054,

G055

f f

UINT Interrupt signal for custom

macro

G053#3 f f

UO000 to

UO015

Output signal for custom

F054,

F055

f f

UO100 to

UO131

Output signal for custom

macro

F056 to

F059

f f

WATO Waiting signal F063#6 F F

WOQSM Workpiece coordinate

system shift value write

mode select signal

G039#6 f –

WOSET Workpiece coordinate

system shift value write

signal

G040#7 f –

XAE X004#0 f f

YAE

Measuring position reached

X004#1 – f

ZAE

Measuring position reached

signal

X004#1 f –

ZAE X004#2 – f
