7. PARAMETERS

369

05304 Tapping axis in–position width in rigid tapping

using the third spindle [Detection unit]

05305 Spindle in–position width in rigid tapping using

the third spindle [Detection unit]

05308 In–position width at point R in rigid tapping

(tapping axis) [Detection unit]

05310 Limit value of tapping axis positioning deviation

during movement in rigid tapping

PRM5314

05311 Limit value of spindle positioning deviation

during movement in rigid tapping

05312 Limit value of tapping axis positioning deviation

during stop in rigid tapping

05313 Limit value of spindle positioning deviation

during stop in rigid tapping

05314 Limit of position deviation during movement

along the tapping axis for rigid tapping

(0 to 99999999)

PRM5310

when 0 is

specified

05321

Spindle backlash in rigid tapping

(first–stage gear)

T series

Spindle backlash in rigid tapping M series

05322 Spindle backlash in rigid tapping

(second–stage gear)

T series

05323 Spindle backlash in rigid tapping

(third–stage gear)

T series

05324 Spindle backlash in rigid tapping

(fourth–stage gear)

T series

05325

Spindle backlash in rigid tapping using the

second spindle (first–stage gear)

T series

Spindle backlash in rigid tapping using the

second spindle

M series

05326 Spindle backlash in rigid tapping using the

second spindle (second–stage gear)

T series

05327

Spindle backlash in rigid tapping using the third

spindle (first–stage gear)

T series

Spindle backlash in rigid tapping using the third

spindle

M series

05328 Spindle backlash in rigid tapping using the third

spindle (second–stage gear)

T series

05335 Time constant for the spindle and tapping axis

in second spindle extraction operation

(first–stage gear) [ms]
