17.4 Spindle Setting and Tuning Screen

860

D Control input signal

Max.10 signals those are ON are displayed from the following signals:

TLML : Torque limit command (low)

TLMH : Torque limit command (high)

CTH1 : Gear signal 1

CTH2 : Gear signal 2

SRV : Spindle reverse rotation

SFR : Spindle forward rotation

ORCM : Spindle orientation

MEDY : Machine ready

ARST : Alarm reset signal

*ESP : Emergency stop

SPSL : Spindle selection signal

MCFN : Power line switching

SOCN : Soft start/stop

RSL : Output switching request

RCH : Power line state confirm

INDX : Orientation stop pos.

change

ROTA : Rotation direction of

ORCM

NRRO : Short–cut of ORCM

INTG : Speed integral control

signal

DEFM : Referential mode

command

[Reference] Control input signal address for each spindle

First spindle : <G070–G073>

Second spindle : <G074–G077>

Third spindle : <G204–G207>

Fourth spindle : <G266–G269>

D Control output signals

Max. 10 signals those are ON are displayed from the following signals:

ALM : Alarm signal

SST : Speed zero signal

SDT : Speed detecting signal

SAR : Speed arrival signal

LDT1 : Load detecting signal 1

LDT2 : Load detecting signal 2

TML5 : Torque limitation

ORAR : Orientation end signal

CHP : Power line switched signal

CFIN : Spindle switch complete

RCHP : Output switch signal

RCFN : Output switch complete

signal

[Reference] Control output signal address for each spindle

First spindle : <F045–F048>

Second spindle : <F049–F052>

Third spindle : <F168–F171>

Fourth spindle : <F266–F269>
