9. SIGNAL LIST (X/Y, G/F)

583

Symbol

series

AddressSignal name

RTE Manual rapid traverse

selection signal

(PMC axis control)

G150#6 f f

RTO Software operator’s panel

signal (RT)

F077#6 f f

RTNT Rigid tapping retraction

start signal

G062#6 – f

RTPT Rigid tapping retraction

completion signal

F066#1 – f

RTRCT Retract signal G066#4 f f

RTRCTF Retract completion signal F065#4 f f

RVS Retrace signal G007#0 – f

RVSL Retrace–in–progress signal F082#2 – f

RWD Rewinding signal F000#0 f f

S00 to S31 Spindle function code

signal

F022 to

F025

f f

S1MES Spindle 1 under

measurement signal

F062#3 f –

S2MES Spindle 2 under

measurement signal

F062#4 f –

S2TLS Spindle measurement

select signal

G040#5 f –

SA Servo ready signal F000#6 f f

SAR Spindle speed arrival signal G029#4 f f

SARA F045#3 f f

SARB

Speed arrival signal

F049#3 f f

SARC

Speed arrival signal

(serial spindle)

F168#3 f f

SARD F266#3 f f

SBK Single block signal G046#1 f f

SBKO Software operator’s panel

signal (SBK)

F075#3 f f

SCLP Spindle clamp signal F038#0 f –

SDTA F045#2 f f

SDTB

Speed detection signal

F049#2 f f

SDTC

Speed detection signal

(serial spindle)

F168#2 f f

SDTD F266#2 f f

SF Spindle speed strobe signal F007#2 f f

SFIN Spindle function completion

signal

G005#2 f f

SFRA G070#5 f f

SFRB

CW command signal

G074#5 f f

SFRC

CW command signal

(serial spindle)

G204#5 f f

SFRD G266#5 f f
