8. ALARM LIST

537

No.

LED

display

Description Countermeasure

303

An LED disconnection

(LDAL) was detected in the

serial pulse coder.

Turn the power off. If this

alarm recurs when the

power is reapplied, replace

the motor.

304

A mispulse alarm (PMAL)

for the serial pulse coder

was detected.

Turn the power off. If this

alarm recurs when the

power is reapplied, replace

the motor.

305

A miscount alarm (CMAL)

for the serial pulse coder

was detected.

Turn the power off. If the

alarm recurs when the

power is re–applied, replace

the motor.

If the alarm does not recur,

restart the operation from

reference position return.

306

The motor has overheated

(OHAL).

This alarm is issued when

the motor has overheated,

causing the thermostat to

trip.

Possible causes include an

excessively high ambient

temperature and exces-

sively strict operating condi-

tions. Check the actual

cause.

If it occurs again when the

motor is cooled, the motor or

servo amplifier may have

failed. Replace the faulty

motor or servo amplifier.

308

A soft phase alarm (SPHAL)

was detected.

Turn the power off. This

alarm may be caused by

noise.

319

When the absolute pulse

coder is used, the motor has

not yet rotated through more

than one turn after the first

power–up.

Cause the motor to rotate

through more than one turn

in jog feed mode, then turn

the power off then back on.

350

The battery voltage of the

absolute pulse coder is low.

Replace the battery.

Restart the operation from

reference position return.

351

The battery voltage of the

absolute pulse coder is low.

(warning)

Replace the battery.

401

A communication error was

detected in the serial pulse

coder.

Check the continuity of the

pulse coder signal cable. If

the cable is normal, the

pulse coder or servo amplifi-

er unit may be defective.

This error can also be

caused by external noise.
