18.5 Periodic Maintenance Screens

884

18.5.4 Setting screen display and setting

The setting screen lets you specify the service life, the remaining service

time, and count type for a registered item name.

It also displays the same count status information as displayed on the status

screen.

PERIODICAL MAINTENANCE O0001 N12345

(SETTING)

LIFE REMAIN COUNT TYPE

*01 10000H 0H ALL TIME

@02 20000H 5000H LIV TIME

03 32767H 10000H ––––––––

@04 1500H 720H RUN TIME

EDIT *** ***** *** **** 19:27:05

[ CHANGE ][ TYPE ][ CLEAR ][ +INPUT ][ INPUT ]

[ EFFECT ][ ALL ][ LIV ][ RUN ][ CUT ]

[ ][ READ ][ PUNCH ][ ][ ]

(1) Service life

The service life of a consumable item is to be specified under “Service

life.”

First place the cursor on the service life of a target registration number,

enter a desired service life value. At this time, the same value is also

set for the remaining service time, and the count type is displayed as

“______”.

The valid data range for the service life is: 0 to 65535 (hours)

(2) Remaining service time

The remaining service time of an item (the time allowed before the item

is replaced) is determined by count–down and displayed under

“Remaining service time.” When the remaining service time

decreases to a specified percentage (specified in PRM8911) of the

service life or lower, it is displayed in red.

Count–down continues even after the service life has expired.

First place the cursor on the remaining service time of a target

registration number, enter a desired remaining service time value.
