7. PARAMETERS

459

19541 Optimum torque acceleration/deceleration

(speed at P1) [0.01%]

<Axis>

M series

19542 Optimum torque acceleration/deceleration

(speed at P2) [0.01%]

PRM1420 to

be set as

the ratio to

19543 Optimum torque acceleration/deceleration

(speed at P3) [0.01%]

PRM1420

19544 Optimum torque acceleration/deceleration

(speed at P4) [0.01%]

19545 Optimum torque acceleration/deceleration

(acceleration at P0 during movement in +

direction and acceleration) [0.01%]

<Axis>

M series

To be set

19546 Optimum torque acceleration/deceleration

(acceleration at P1 during movement in +

direction and acceleration) [0.01%]

as the ratio

to a refer-

ence ac-

celeration

19547 Optimum torque acceleration/deceleration

(acceleration at P2 during movement in +

direction and acceleration) [0.01%]

value.

PR1773

and 1620

are used

19548 Optimum torque acceleration/deceleration

(acceleration at P3 during movement in +

direction and acceleration) [0.01%]

to set a

reference

accelera-

tion value.

19549 Optimum torque acceleration/deceleration

(acceleration at P4 during movement in +

direction and acceleration) [0.01%]

tion value.

When 0 is

set in the

above,

19550 Optimum torque acceleration/deceleration

(acceleration at P5 during movement in +

direction and acceleration) [0.01%]

above,

1000

mm/sec

100

inch/sec

19551 Optimum torque acceleration/deceleration

(acceleration at P0 during movement in –

direction and acceleration) [0.01%]

100

deg/sec

19552 Optimum torque acceleration/deceleration

(acceleration at P1 during movement in –

direction and acceleration) [0.01%]

19553 Optimum torque acceleration/deceleration

(acceleration at P2 during movement in –

direction and acceleration) [0.01%]

19554 Optimum torque acceleration/deceleration

(acceleration at P3 during movement in –

direction and acceleration) [0.01%]

19555 Optimum torque acceleration/deceleration

(acceleration at P4 during movement in –

direction and acceleration) [0.01%]

19556 Optimum torque acceleration/deceleration

(acceleration at P5 during movement in –

direction and acceleration) [0.01%]
