7.2 Parameter List

438

08512 Switch setting (Direction setting of direction

decision type when the signal is on)

#0 HA1 : The passage direction in which the first

high–speed position switch is turned on is, –

(0)/+ (1)

#1 HA2 : The passage direction in which the second

high–speed position switch is turned on is, –

(0)/+ (1)

#2 HA3 : The passage direction in which the third

high–speed position switch is turned on is, –

(0)/+ (1)

#3 HA4 : The passage direction in which the fourth

high–speed position switch is turned on is, –

(0)/+ (1)

#4 HA5 : The passage direction in which the fifth

high–speed position switch is turned on is, –

(0)/+ (1)

#5 HA6 : The passage direction in which the sixth

high–speed position switch is turned on is, –

(0)/+ (1)

#6 HA7 : The passage direction in which the seventh

high–speed position switch is turned on is, –

(0)/+ (1)

#7 HA8 : The passage direction in which the eighth

high–speed position switch is turned on is, –

(0)/+ (1)

For the

positions

where the

switches

are turned

on, see

PRM8580

to 8587.

08513 Switch setting (Direction setting of direction

decision type when the signal is on)

#0 HA9 : The passage direction in which the ninth

high–speed position switch is turned on is, –

(0)/+ (1)

#1 HAA : The passage direction in which the tenth

high–speed position switch is turned on is, –

(0)/+ (1)

#2 HAB : The passage direction in which the eleventh

high–speed position switch is turned on is, –

(0)/+ (1)

#3 HAC : The passage direction in which the twelfth

high–speed position switch is turned on is, –

(0)/+ (1)

#4 HAD : The passage direction in which the thirteenth

high–speed position switch is turned on is, –

(0)/+ (1)

#5 HAE : The passage direction in which the fourteenth

high–speed position switch is turned on is, –

(0)/+ (1)

#6 HAF : The passage direction in which the fifteenth

high–speed position switch is turned on is, –

(0)/+ (1)

#7 HAG : The passage direction in which the sixteenth

high–speed position switch is turned on is, –

(0)/+ (1)

For the

positions

where the

switches

are turned

on, see

PRM8588

to 8589

and 12221

to 12226.
