13.2 Diagnosis Information (DGN) List

764

13.2.12 Displacement detection (DGN305)

305

Position feedback data between Z phases of individual axes

[Detection unit]

DGN

If displacement detection is enabled, the feedback data between the Z

phases of different axes is represented.

13.2.13 Machine coordinates of inclined axis/orthogonal axis

(DGN306, 307)

306

Machine coordinates of a inclined axis in the Cartesian coordi-

nate system [Output unit]

DGN

307

Machine coordinates of an orthogonal axis in the Cartesian coor-

dinate system [Output unit]

DGN

These parameters are updated only when PRM8200#0 (AAC) is set to 1,

and any of the parameters below is set to 1:

D PRM8201#0 (AOT)

D PRM8201#1 (AO2)

D PRM8201#2 (AO3)

D PRM5009#3 (QSA) (T series only)

D The interference check option is selected.

13.2.14 Servo motor temperature information (DGN308, 309)

308

Servo motor temperature [_C]

DGN

The αi servo motor coil temperature is indicated.

Information on axes other than the αi servo axis is not indicated. (Indicated

by “0_C.”)

When the temperature reaches 140_C, an alarm about motor overheat is

issued.

309

Pulse coder temperature [_C]

DGN

The temperature of the pulse coder printed circuit board is indicated.

Information on axes other than the αi servo axis is not indicated. (Indicated

by “0_C.”)

When the temperature reaches 100_C (85_C for the atmosphere

temperature in the pulse coder), an alarm about motor overheat is issued.
