19. MAINTENANCE FUNCTION

929

(2) Select the file to be deleted.

1 Using the [UP] or [DOWN] soft key, position the cursor to the

desired file name.

SELECT

[][][][][]

YES NO UP DOWN

MEMORY CARD FILE DELETE

FILE DIRECTORY

MACRO1. MEM

MACRO2. MEM

LADDER. ROM

END

1/1

***MESSAGE***

SELECT FILE AND HIT SELECT KEY.

Previous screen Next screen

D When the file list is too large to be displayed on one screen, the

previous and subsequent pages can be viewed by using the

and soft keys.

D To return to the SYSTEM MONITOR MAIN MENU screen, position

the cursor to END, then press the [SELECT] soft key.

2 Press the [SELECT] key.

(3) A confirmation message appears at the bottom of the screen. To delete

the file, press the [YES] soft key. To abandon the deletion, press the

[NO] soft key.

D Once the file has been deleted, “HIT SELECT KEY” appears at the

bottom of the screen.

(4) Press the [SELECT] soft key to return to the MEMORY CARD FILE

DELETE screen.

19.3.8 Memory card format

F Formatting a memory card (MEMORY CARD FORMAT screen)

H A newly purchased memory card must be formatted before it can

be used. Also, a memory card must be formatted if its contents are

destroyed or lost due to battery failure.

(1) Select the MEMORY CARD FORMAT screen.

1 Using the [UP] or [DOWN] soft key, position the cursor to 7.

MEMORY CARD FORMAT on the SYSTEM MONITOR MAIN

MENU screen.

2 Press the [SELECT] key.

(2) A confirmation message appears at the bottom of the screen. To format

the memory card, press the [YES] soft key. To abandon the formatting,

press the [NO] soft key.

D While the memory card is being formatted, the message

“FORMATTING MEMORY CARD” is displayed at the bottom of the

screen.

D Once formatting has been completed, “FORMATTING COMPLETE

HIT. SELECT KEY” appears at the bottom of the screen.

(3) Press the [SELECT] soft key to return to the SYSTEM MONITOR MAIN

MENU screen.
