19.3 Boot System (System Monitor)

932

Cause and ResponseMessage

M MAX EXTENSION OVER.

HIT SELECT KEY.

The extension number added to a file name

exceeds 31. Delete any unnecessary backup

files from the memory card.

MEMORY CARD BAT-

TERY ALARM.

HIT SELECT.

The memory card’s battery is exhausted. Re-

place the battery.

MEMORY CARD FULL.

HIT SELECT KEY.

The memory card is full. Delete any unnec-

essary files from the memory card. Alterna-

tively, replace the memory card with another

card having sufficient free space.

MEMORY CARD IS NOT

AVAILABLE. HIT SEL.

The use of this memory card is not sup-

ported. Use only FANUC–recommended

memory cards, as described in the order list.

MEMORY CARD MOUNT

ERROR.

HIT SELECT KEY

The memory card could not be accessed.

Check that the memory card is normal.

MEMORY CARD NOT EX-

IST.

HIT SELECT KEY.

The memory card is not inserted into its slot.

Check that the memory card is pushed fully

home.

MEMORY CARD PRO-

TECTED.HIT SELECT

KEY.

Although writing to the memory card was se-

lected, the write inhibit switch is set. Disable

the write inhibit switch.

Note) Check that the memory card’s battery

is not exhausted, that its circuitry has

not been damaged, and that it is se-

curely inserted into its slot.

MEMORY CARD RESET

ERROR.

HIT SELECT KEY.

Access to a memory card failed. The

memory card’s battery may have gone dead,

the memory card may have been damaged

electrically, or the memory card may not be

inserted in the slot securely.

MEMORY CARD WRITE

ERROR.

HIT SELECT KEY.

Access to the memory card has failed.

Check whether the memory card is defective.

Note) Check that the memory card’s battery

is not exhausted, that its circuitry has

not been damaged, and that it is se-

curely inserted into its slot.

N NMI OCCURRED.

PLEASE POWER OFF.

A hardware or software error occurred. De-

termine the procedure which causes the er-

ror, and report it to FANUC together with the

series and edition of the boot software.

P PLEASE FORMAT FLASH

TYPE CARD.HIT SEL.

It is not possible to delete only specific files

from a FROM card, due to the characteristics

of the memory used. To delete a file it is nec-

essary to delete all files on the card, by using

the FORMAT function.

R ROM PARITY ERROR:

NC BASIC. HIT SELECT.

The NC BASIC is parity error. Check whether

NC BASIC is in FROM, using SYSTEM DATA

CHECK.
